The MK2300i Series of 2-way, high output, trapezoidal loudspeaker systems are designed as main PA elements for smaller venues, including small houses of worship and auditoriums/theaters, corporate A/V systems, hotel ballrooms and meeting rooms. The Series is also excellent for distributed or fill purposes in larger venues, including large houses of worship and auditoriums/theaters, arenas, stadiums, nightclubs, and themed-entertainment complexes.
To meet the design goals for the intended applications, EAW engineers developed a new, high performance, 3-inch voice coil, 1.4-in exit compression driver, loading it with a selection of six different HF horns with coverage patterns ranging from 60° x 45° to 120° x 60°. The horns are as large as the enclosure size allows to maintain consistent directivity throughout the HF passband. A 3-inch voice coil, 12-inch LF driver was used to complement the sonic character and output of the HF driver. All MK2300i models are carefully voiced to sound similar, permitting diverse horn patterns to be mixed throughout an installation while maintaining the same sonic quality. The result is clean, high-fidelity output at significantly higher levels than would be expected from loudspeakers of this size and price.
Users can select between single-amp and bi-amp (external processor) operating modes. In either operating mode, EAW’s beamwidth-matching crossover/ filter design delivers even power response throughout the crossover region, eliminating the discontinuities that plague other two-way loudspeakers.
The MK2300i Series systems are the smaller companions to the MK5300i Series systems. Enclosures for both series are the same height, facilitating installation where more than one horn pattern and/or type of loudspeaker capability is needed. In addition, SBK Series subwoofers also share this height, creating attractive arrays that use EAW’s preconfigured accessory flybar.
• Premium Performance
• Application Flexibility
CONFIGURATION
Subsystem:
Transducer: LF – 1x 12 in. cone; HF – 1x 1.4 in. exit, 3 in. voice coil compression driver
Loading: LF – Vented; HF – Horn-loaded
Operating Mode:
Amplifier Channels: Single-amp LF/HF; Bi-amp LF, HF
External Signal Processing: High pass filter; DSP w/2-way filtersPERFORMANCE
Operating Range (-10 dB, Hz)
65 – 16k
Axial Sensitivity (1W @ 1m, dB SPL)
LF: 97
HF: 107
Full Range: 95
Power Handling/Impedance (Watts @ Ohms)
LF: 600 @ 8
HF: 150 @ 8
Full Range: 600 @ 8
Maximum sound pressure level (dB SPL)
141
Nominal Coverage (degrees)
Horizontal: 60
Vertical: 45ORDERING DATA
Versions
MK2364i Black 2039722
MK2364i White 2039728
MK2364i-WP Black 2039734
Accessories Part Number
Eye Bolt 0.375-16 X 1.25 in, EB3825
104001
U-Bracket MK2(5)000 Black, UBKT2353
0007869
U-Bracket MK2(5)000 White, UBKT2353
0015076
Flybar SBK-MK23 VFS-VFR129 Black, FB2VSK
2038319
Dimensions (inches/millimeters)
Height: 30.00/762
Width (front): 15.54/394.7
Width (rear): 8.75/222
Depth: 14.75/374.7
Trap. Angle (degrees per side): 15
Weights (pounds/kilograms)
Net: 60/27.2
Shipping: 70/31.8
