4 Channel Analog Output Card
Overview
The analog output card provides four channels of line level output. The outputs are electronically balanced and provided on plug-in barrier strip connectors. Control of each output includes gain with metering and mute.
Specification
Analog line outputs.
4 channels per card.
High output levels for long cable runs. Up to +24 dBu.
Digital trim. +12dB down to full off.
Extended dynamic range D/A converters. >117 dB.
3.81mm terminal blocks, 12 position plugs with strain relief pull tabs.
Field swappable by qualified technicians.
